generally

• size

• 70.5 mm long, 44.2 mm wide, 32.8 mm high

• weight

• 145 grams

• water proof

• Bare metal 16 meters ¹ , with waterproof case 60 meters

• microphone

• 3

• touch screen

• Front screen: 1.4 inches 326 ppi 320×320
  Rear screen: 2.25 inches 326 ppi 360×640
  Front and rear screen brightness: 750±50 cd/m²

• Supported memory card types

• microSD card (maximum capacity supports 256GB)

• Recommended microSD card list

• Recommended models:
  SanDisk Extreme 32GB V30 A2 UHS-I Speed ​​Grade 3
  SanDisk Extreme Pro 32GB V30 A2 UHS-I Speed ​​Grade 3
  Kingston Canvas Go!Plus 64GB UHS-I Speed ​​Grade 3
  Kingston Canvas Go!Plus 128GB UHS-I Speed ​​Grade 3
  Kingston Canvas React Plus 64GB UHS-II Speed ​​Grade 3
  Kingston Canvas React Plus 128GB UHS-II Speed ​​Grade 3
  Kingston Canvas React Plus 256GB UHS-II Speed ​​Grade 3
  Samsung Pro Plus 256GB V30 A2 UHS-I Speed ​​Grade 3

camera

• Photosensitive element

• 1/1.7 inch sensor

• lens

• Viewing angle: 155°
  Aperture: f/2.8
  Focus range: 0.3 meters to infinity

• ISO range

• Photo: 100 to 12800
  Video: 100 to 12800

• electronic shutter speed

• Photo: 1/8000 sec to 30 sec Video: 1/8000 sec to frame rate limit shutter

• Maximum photo resolution

• 4000×3000

• zoom

• Digital zoom photography: 4x Video recording: 2x (>60fps), 3x (≤60fps, turn on horizon stabilization), 4x (≤60fps, turn off horizon stabilization)
  Slow motion/time lapse: not supported

• Photo shooting mode

• Single photo: 12 million pixels Countdown photo: off/0.5/1/2/3/5/10 seconds

• General specifications recording

• 4K (4:3): 4096×3072@24/25/30/48/50/60fps
  4K (16:9): 3840×2160@100/120fps
  4K (16:9): 3840×2160@24/25/30/48/50/60fps
  2.7K (4:3): 2688×2016@24/25/30/48/50/60fps
  2.7K (16:9): 2688×1512@100/120fps
  2.7K (16:9): 2688×1512@24/25/30/48/50/60fps
  1080p (16:9): 1920×1080@100/120/200/240fps
  1080p (16:9): 1920×1080@24/25/30/48/50/60fps

• slow motion video

• 4K: 4x (120fps)
  2.7K: 4x (120fps)
  1080p: 8x (240fps), 4x (120fps)

• motion time lapse

• 4K/2.7K/1080p: Auto/×2/×5/×10/×15/×30

• still time lapse

• 4K/2.7K/1080p@30fps
  Shooting interval: 0.5/1/2/3/4/5/6/7/8/10/13/15/20/25/30/40 seconds Shooting time length: 5/10/20/30 minutes, 1/ 2/3/5 hours, unlimited time

• HDR video

• 4K (16:9): 3840×2160@24/25/30fps
  2.7K (16:9): 2688×1512@24/25/30fps
  1080p: 1920×1080@24/25/30fps

• increase stability

• Electronic stabilization ² :
  RockSteady 3.0 Super Stability Enhancement
  RockSteady 3.0 Super Stabilization+
  HorizonBalancing horizon correction
  HorizonSteady horizon stabilization

• Video storage maximum data transfer rate

• 130Mbps

• Support file system

• exFAT

• Image Format

• JPEG/RAW

• video format

• MP4 (H.264/HEVC)

• Built-in memory capacity

• No built-in storage, storage can be expanded via microSD card slot

• audio output

• 48 kHz; AAC

Battery

• type

• LiPo 1S

• capacity

• 1770 mAh

• energy

• 6.8 watt hours

• Voltage

• 3.85 volts

• Operating environment temperature

• -20°C to 45°C

• Charging ambient temperature

• 5°C to 40°C

• Battery life

• 160 minutes ³

connect

• Wi-Fi operating frequency

• 2.400 GHz to 2.4835 GHz
  5.150 GHz to 5.250 GHz
  5.725 GHz to 5.850 GHz

• Wi-Fi protocol

• 802.11 a/b/g/n/ac

• Wi-Fi transmit power (EIRP)

• 2.4 GHz: <16 dBm (FCC/CE/SRRC/MIC)
  5.1 GHz: <14 dBm (FCC/CE/SRRC/MIC)
  5.8 GHz: <14 dBm (FCC/CE/SRRC)

• Bluetooth operating frequency

• 2.400 GHz to 2.4835 GHz

• Bluetooth transmit power (EIRP)

• <4dBm

• Bluetooth protocol

• BLE 5.0

Remark

• 1. Before use, please ensure that the battery compartment protective cover and USB-C port protective cover are tightly closed, and tighten the lens protective cover. If it is used underwater for a long time or in scenes with high water impact pressure, it is recommended to install a waterproof case. Both the Osmo Action 3 and the waterproof case have passed the GB/T 4208-2017 and IEC 60529-2013 case protection grade standard IP68 waterproof test. It is not recommended to use this product in extreme water wading environments or unknown liquids. Do not use it in hot springs or corrosive liquids.
  2. Still time-lapse photography and slow-motion modes do not support electronic stabilization. HorizonSteady horizon stabilization only supports 1080p/2.7K videos in 16:9 format (≤60fps), and HorizonBalancing horizon correction only supports 1080p/2.7K/4K videos in 16:9 format (≤60fps).
  3. Measured in a laboratory environment of 25°C, using normal video mode, turning off image quality enhancement, setting the video resolution to 1080p/30fps, turning off electronic stabilization, and keeping the screen off. For reference only.
